The DAS Solar 620 W Commercial Module combines advanced N-Type TOPCon bifacial cell technology with premium commercial-grade construction. Designed for industrial and large-scale rooftop or ground-mount installations, its exceptional output, efficiency and durability make it a standout in high-performance solar.

Key Features

620 W maximum power output — one of the highest per-panel outputs available.
Module efficiency up to ~23.0% — enabling superior energy yield in commercial arrays.
N-Type TOPCon bifacial technology — double glass design, capable of up to ~30% extra energy from rear side under favourable conditions.
Module dimensions — 2,382 mm × 1,134 mm × 30 mm, weighing ~31.9 kg.
High durability ratings — front load 5,400 Pa, back load 2,400 Pa; operating temperature range –40 °C to +85 °C.
1500 V system voltage compatible — ideal for large commercial installations.
Warranty — 15-year materials and workmanship warranty; 30-year linear performance warranty ensuring long term return on investment.

Technical Specification (Summary)

Parameter	Specification
Maximum Power (P max)	620 W (STC)
Efficiency	Up to 23.0%
Open Circuit Voltage (Voc)	~48.35 V
Short Circuit Current (Isc)	~16.12 A
Dimensions (L × W × D)	2,382 mm × 1,134 mm × 30 mm
Weight	~31.9 kg
Operating Temp Range	–40 °C to +85 °C
System Voltage	1,500 V DC
Load Capacity	Front: 5,400 Pa / Back: 2,400 Pa

Downloads

DAS 620W Data Sheet

DAS 620W MCS Certification

DAS 620W Warranty Document

DAS ESG Report
